Choice A is correct. It’s given that points \( A \) and \( B \) lie on the circle with center \( C \). Therefore, \( \overline{AC} \) and \( \overline{BC} \) are both radii of the circle. Since all radii of a circle are congruent, \( \overline{AC} \) is congruent to \( \overline{BC} \). The length of \( \overline{AC} \), or the distance from point \( A \) to point \( C \), can be found using the distance formula, which gives the distance between two points, \( (x_{1}, y_{1}) \) and \( (x_{2}, y_{2}) \), as \( \sqrt{(x_{1} – x_{2})^{2} + (y_{1} – y_{2})^{2}} \). Substituting the given coordinates of point \( A \), \( (h + 1, k + \sqrt{102}) \), for \( (x_{1}, y_{1}) \) and the given coordinates of point \( C \), \( (h, k) \), for \( (x_{2}, y_{2}) \) in the distance formula yields \( \sqrt{(h + 1 – h)^{2} + (k + \sqrt{102} – k)^{2}} \), or \( \sqrt{1^{2} + (\sqrt{102})^{2}} \), which is equivalent to \( \sqrt{1 + 102} \), or \( \sqrt{103} \). Therefore, the length of \( \overline{AC} \) is \( \sqrt{103} \) and the length of \( \overline{BC} \) is \( \sqrt{103} \). It’s given that angle \( ACB \) is a right angle. Therefore, triangle \( ACB \) is a right triangle with legs \( \overline{AC} \) and \( \overline{BC} \) and hypotenuse \( \overline{AB} \). By the Pythagorean theorem, if a right triangle has a hypotenuse with length \( c \) and legs with lengths \( a \) and \( b \), then \( a^{2} + b^{2} = c^{2} \). Substituting \( \sqrt{103} \) for \( a \) and \( b \) in this equation yields \( (\sqrt{103})^{2} + (\sqrt{103})^{2} = c^{2} \), or \( 103 + 103 = c^{2} \), which is equivalent to \( 206 = c^{2} \). Taking the positive square root of both sides of this equation yields \( \sqrt{206} = c \). Therefore, the length of \( \overline{AB} \) is \( \sqrt{206} \).
Choice B is incorrect and may result from conceptual or calculation errors. Choice C is incorrect. This would be the length of \( \overline{AB} \) if the length of \( \overline{AC} \) were 103, not \( \sqrt{103} \). Choice D is incorrect and may result from conceptual or calculation errors.
Choice A is correct. It’s given that points \( A \) and \( B \) lie on the circle with center \( C \). Therefore, \( \overline{AC} \) and \( \overline{BC} \) are both radii of the circle. Since all radii of a circle are congruent, \( \overline{AC} \) is congruent to \( \overline{BC} \). The length of \( \overline{AC} \), or the distance from point \( A \) to point \( C \), can be found using the distance formula, which gives the distance between two points, \( (x_{1}, y_{1}) \) and \( (x_{2}, y_{2}) \), as \( \sqrt{(x_{1} – x_{2})^{2} + (y_{1} – y_{2})^{2}} \). Substituting the given coordinates of point \( A \), \( (h + 1, k + \sqrt{102}) \), for \( (x_{1}, y_{1}) \) and the given coordinates of point \( C \), \( (h, k) \), for \( (x_{2}, y_{2}) \) in the distance formula yields \( \sqrt{(h + 1 – h)^{2} + (k + \sqrt{102} – k)^{2}} \), or \( \sqrt{1^{2} + (\sqrt{102})^{2}} \), which is equivalent to \( \sqrt{1 + 102} \), or \( \sqrt{103} \). Therefore, the length of \( \overline{AC} \) is \( \sqrt{103} \) and the length of \( \overline{BC} \) is \( \sqrt{103} \). It’s given that angle \( ACB \) is a right angle. Therefore, triangle \( ACB \) is a right triangle with legs \( \overline{AC} \) and \( \overline{BC} \) and hypotenuse \( \overline{AB} \). By the Pythagorean theorem, if a right triangle has a hypotenuse with length \( c \) and legs with lengths \( a \) and \( b \), then \( a^{2} + b^{2} = c^{2} \). Substituting \( \sqrt{103} \) for \( a \) and \( b \) in this equation yields \( (\sqrt{103})^{2} + (\sqrt{103})^{2} = c^{2} \), or \( 103 + 103 = c^{2} \), which is equivalent to \( 206 = c^{2} \). Taking the positive square root of both sides of this equation yields \( \sqrt{206} = c \). Therefore, the length of \( \overline{AB} \) is \( \sqrt{206} \).
Choice B is incorrect and may result from conceptual or calculation errors. Choice C is incorrect. This would be the length of \( \overline{AB} \) if the length of \( \overline{AC} \) were 103, not \( \sqrt{103} \). Choice D is incorrect and may result from conceptual or calculation errors.
